TUB.3/05-08

TUB.3/05-08 Super Low Profile Scissor Lift Table (500 kg)
The TUB.3/05-08 Super Low Profile Scissor Lift Table is developed for lifting and positioning palletized loads with a rated capacity of 500 kg, combining an ultra-low closed height with reliable hydraulic lifting performance.
Overview
The Super Low Profile Scissor Lift Table is a compact lifting solution designed for floor-level loading and ergonomic load handling.
Thanks to its ultra-low closed height, the platform can be fed by a hand or electric pallet truck without the need for a pit or ramp, making it ideal for retrofit projects and quick installations.
With a customer-focused design approach, key parameters such as capacity, stroke, platform sizing and control configuration can be adapted to project requirements.
Key Benefits
• Floor-level loading for pallet truck operations and fast material flow
• Ultra-low closed height for space-saving integration
• Smooth lifting and stable positioning for repeatable workflows
• Low maintenance design for long-term industrial use
• Custom manufacturing for project-specific needs
Typical Applications
• Packaging and palletizing lines
• Production line infeed/outfeed stations
• Warehouse pallet transfer and staging areas
• Conveyor and automation integrations
• Workstations requiring ergonomic height adjustment
Safety and Standard Equipment
• 24 V low-voltage control system for safer operation
• Hold-to-run (deadman) or push-button automatic control options
• Overload protection
• Safety frame on the platform deck to help prevent trapping hazards
• Hose burst valve to reduce the risk of sudden descent
• Reinforced hydraulic hoses to minimize impact damage risk
• Mechanical safety maintenance stop for secure service operations
• All lift tables are tested at +30% overload (relative to rated capacity)
• Designed safety clearances between moving components
• Bearing rollers with reduced lubrication needs for low maintenance
Options and Accessories
• Optional approach ramp (to simplify pallet truck entry depending on site conditions)
• Bellows / skirting to protect the scissor area
• Guard rails and safety barriers
• Turntable and load positioning accessories
• Special coating/finishes and outdoor adaptations (project-based)
• Crane lifting points and handling provisions
Technical Specifications (Summary)
Type (Model): TUB.3/05-08
Article No: 78.05.001
Capacity: 500 kg
Platform size (ExF): 1200 x 1270 mm
Stroke (H): 800 mm
Closed height (C): 10 mm
Lifting time: 21 sec
Motor power: 0.75 kW
Unit weight: On request
Request a Quote
For model selection, customization and quotation, contact our technical team.
