MPD scissor lift manlift series adopts pure hydraulic drive, the working height covers 10 m the maximum load is up to 400 kg, using the battery as the power, energy saving, and environmental protection, zero-emission, noiseless, suitable for indoor flat ground and high-altitude operation environment with high environmental requirements.
Aerial Work Platform
Scissor Lift
MPD.1012
Technical Documents
TECHNICAL SPECIFICATIONS
MPD.1012
Dimensions
A- Working Height
10,00 M
B - Platform Height - Lifted
8,00 M
D - Platform Height - Lowered
1,24 M
D+C - Closed Height - Stowed Handrails
2,39 M
Closed Height (Handrails Folded)
1,87 M
C - Handrails Height
1,10 M
E X F - Platform Dimensions
2,30 x 1,15 M
K - Extension Deck
0,90 M
G - Total Width
1,15 M
L - Total Length
2,49
J- Wheelbase
1,89 M
Ground Clearance -Center
10 CM
Ground Clearance Pothole Deployed
25 MM
Productivity
Lift Capacity
400 KG
Extension Deck Capacity
100 KG
Maximum Occupancy
2
Rise / Lower Time
50 / 45 SEC
Weight
2675 KG
Gradeability
20 %
Drive Speed ( Rised / Stowed )
0,8 / 2,4 KM
Tyres - Solid non-marking
15x5
Turning Radius
2500
Drive Type
Front Wheel-Hydraulic
Brake
Rear Wheel - Hydraulic
Power
Walking Type
Hydraulic
Power Source
24 V Battery
Battery
4x6V 242 Ah
Charger
24V 30 Ah
